| Onderdeel nommer | AV080WSM-NW2 |
| Handelsmerk | BOE |
| Grootte | 8.0 |
| Toepassing | Automotive Display |
| Resolusie | 1024×600 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleure | 262K/16.7M |
| Agterlig | 3S10P |
| Koppelvlak | LVDS |
| vervaardiger | BOE |
| model naam | AV080WSM-NW2 |
| skerm grootte | 8.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1024(RGB)×600 (WSVGA) 148PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 176.64 × 99.36 (H×V) |
| buitelyn (mm) | 192.8 × 116.9 × 4.7 (H×V×D) |
| ring area (mm) | 180.1 × 103.4 (H×V) |
| behandeling | - |
| helderheid | 600 cd/m² (Typ.) |
| kontras verhouding | 800 : 1 (Typ.) (TM) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | ADS, Normally Black, Transmissive |
| kleurdiepte | 262K/16.7M 50% NTSC |
| agterlig | 3S10P WLED , 30K hours , No Driver |
| massa | 176/180g (Typ./Max.) |
| gebruik vir | Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (1 ch, 6/8-bit) , FPC 40 pins |
| spanningstoevoer | 3.3/11.5/21/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
