| Onderdeel nommer | AM-640480VTZQW-A0H |
| Handelsmerk | AMPIRE |
| Grootte | 5.7 |
| Toepassing | Industrial |
| Resolusie | 640×480 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1200:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | AMPIRE |
| model | AM-640480VTZQW-A0H |
| diagonale grootte | 5.7 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 640(RGB)×480 [VGA] 141PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 115.2(H)×86.4(V) mm |
| buitelyn dof. | 127(H)×98.43(V) ×7.8(D) mm |
| ring area | 118.0(H)×89.2(V) mm |
| behandeling | - |
| helderheid | 500 cd/m² (Typ.) |
| kontras verhouding | 1200:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedryfsmodus | IPS, Normally Black, Transmissive |
| ondersteun kleur | 262K 63% NTSC |
| Ligbron | WLED [4S7P] , 50K hours , W/O Driver |
| gewig | - |
| ontwerp vir | Industrial |
| raamkoers | 60Hz |
| raakpaneel | Without |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
