| Onderdeel nommer | AM-640480GSTMQW-00H-A |
| Handelsmerk | AMPIRE |
| Grootte | 5.7 |
| Toepassing | Industrial |
| Resolusie | 640×480 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 600:1 |
| Kleure | 262K |
| Agterlig | 3S7P |
| Koppelvlak | |
| paneel handelsmerk | AMPIRE |
| paneel grootte | 5.7" |
| resolusie | 640(RGB)×480, VGA, 141PPI |
| vertoon area | 115.2(W)×86.4(H) mm |
| omtrek grootte | 144(W)×104.6(H) ×12.6(D) mm |
| helderheid | 400 cd/m² (Typ.) |
| kykhoek | 75/75/65/65 (Typ.)(CR≥10) |
| beste uitsig op | 6 o'clock |
| kleure vertoon | 262K 50% NTSC |
| frekwensie | 60Hz |
| gewig | - |
| paneel model | AM-640480GSTMQW-00H-A |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 118.2(W)×89.4(H) mm |
| oppervlak | Antiglare |
| kontras verhouding | 600:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 50 (Typ.)(Tr+Td) |
| tipe lamp | 3S7P WLED , 20K hours , With LED Driver |
| raakskerm | Without |
| aansoek | Industrial |
