| Onderdeel nommer | AM-640480G2TNQW-A0H |
| Handelsmerk | AMPIRE |
| Grootte | 5.7 |
| Toepassing | Industrial |
| Resolusie | 640×480 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 250:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | AMPIRE |
| model | AM-640480G2TNQW-A0H |
| diagonale grootte | 5.7 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 640(RGB)×480 [VGA] 141PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 115.2(H)×86.4(V) mm |
| buitelyn dof. | 127(H)×98.43(V) ×7.8(D) mm |
| ring area | 118.0(H)×89.2(V) mm |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 500 cd/m² (Typ.) |
| kontras verhouding | 250:1 (Typ.) (TM) |
| kyk rigting | 12 o'clock |
| reaksie tyd | 50 (Typ.)(Tr+Td) |
| kykhoek | 70/70/50/50 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 262K 50% NTSC |
| Ligbron | WLED , 20K hours , With LED Driver |
| gewig | - |
| ontwerp vir | Industrial |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | LVDS (1 ch, 6-bit) , 20 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
