| Onderdeel nommer | AM-1280800P4TZQW-T11H |
| Handelsmerk | AMPIRE |
| Grootte | 7.0 |
| Toepassing | Industrial |
| Resolusie | 1280×800 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | 6S4P |
| Koppelvlak | |
| paneel handelsmerk | AMPIRE |
| paneel grootte | 7.0" |
| resolusie | 1280(RGB)×800, WXGA, 217PPI |
| vertoon area | 149.76(W)×93.6(H) mm |
| omtrek grootte | 162.3(W)×107.9(H) ×11.8(D) mm |
| helderheid | 850 cd/m² (Typ.) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 50% NTSC |
| frekwensie | 60Hz |
| gewig | - |
| paneel model | AM-1280800P4TZQW-T11H |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 152.76(W)×96.6(H) mm |
| oppervlak | - |
| kontras verhouding | 800:1 (Typ.) (TM) |
| vertoonmodus | SFT, Normally Black, Transmissive |
| reaksie tyd | 35 (Typ.)(Tr+Td) |
| tipe lamp | 6S4P WLED , 50K hours , With LED Driver |
| raakskerm | PCAP |
| aansoek | Industrial |
