AM-1280800J4TZQW-T00

AM-1280800J4TZQW-T00
AM-1280800J4TZQW-T00 thumb
Handelsmerk
AMPIRE
Grootte
10.1
Toepassing
Industrial
Resolusie
1280×800
Samestelling
a-Si TFT-LCD, LCM
Helderheid
CR
800:1
Kleure
16.7M
Agterlig
WLED
Koppelvlak
LVDS
In Stock
8055
Spesifikasies

Onderdeel nommer AM-1280800J4TZQW-T00
HandelsmerkAMPIRE
Grootte10.1
ToepassingIndustrial
Resolusie1280×800
Samestellinga-Si TFT-LCD, LCM
Helderheid
CR800:1
Kleure16.7M
AgterligWLED
KoppelvlakLVDS
handelsmerkAMPIRE
modelAM-1280800J4TZQW-T00
diagonale grootte10.1 inch
tipea-Si TFT-LCD, LCM
pixel formaat1280(RGB)×800  [WXGA]  149PPI
konfigurasieRGB Vertical Stripe
aktiewe area216.96(H)×135.6(V) mm
buitelyn dof.231(H)×150(V) ×8.8(D) mm
helderheid300 cd/m² (Typ.)
kontras verhouding800:1 (Typ.) (TM)
kyk rigtingSymmetry
reaksie tyd10/15 (Typ.)(Tr/Td)
kykhoek85/85/85/85 (Typ.)(CR≥10)
bedryfsmodusNormally Black, Transmissive
ondersteun kleur16.7M
LigbronWLED  [3S11P] , 15K hours , With LED Driver
gewigTBD
ontwerp virIndustrial
raamkoers60Hz
raakpaneelPCAP
koppelvlak tipeLVDS (1 ch, 8-bit) , 30 pins Connector
kragtoevoer3.3V (Typ.)
omgewingOperating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
