| Onderdeel nommer | AM-1024600K7TMQW-T04H |
| Handelsmerk | AMPIRE |
| Grootte | 7.0 |
| Toepassing | Industrial |
| Resolusie | 1024×600 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 700:1 |
| Kleure | 262K |
| Agterlig | 8S3P |
| Koppelvlak | |
| paneel handelsmerk | AMPIRE |
| paneel grootte | 7.0" |
| resolusie | 1024(RGB)×600, WSVGA, 169PPI |
| vertoon area | 153.6(W)×90(H) mm |
| omtrek grootte | 165.5(W)×104.44(H) ×10.81(D) mm |
| helderheid | 850 cd/m² (Typ.) |
| kykhoek | 75/75/70/75 (Typ.)(CR≥10) |
| beste uitsig op | 6 o'clock |
| kleure vertoon | 262K |
| frekwensie | 60Hz |
| gewig | TBD |
| paneel model | AM-1024600K7TMQW-T04H |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | - |
| kontras verhouding | 700:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 20/20 (Typ.)(Tr/Td) |
| tipe lamp | 8S3P WLED , 50K hours , With LED Driver |
| raakskerm | PCAP |
| aansoek | Industrial |
| A070FW03 V7 | AUO | 7.0 | 480×234 |
| A070VW05 V0 | AUO | 7.0 | 800×480 |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| LB070WV4-SD01 | LG Display | 7.0 | 800×480 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
