| Onderdeel nommer | AC070MR11 |
| Handelsmerk | Mitsubishi |
| Grootte | 7.0 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 800×480 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 262K/16.7M |
| Agterlig | 2 |
| Koppelvlak | LVDS |
| paneel handelsmerk | Mitsubishi |
| paneel grootte | 7.0" |
| resolusie | 800(RGB)×480, WVGA, 133PPI |
| vertoon area | 152.4(W)×91.44(H) mm |
| omtrek grootte | 169.8(W)×109.7(H) ×9.3(D) mm |
| helderheid | 1000 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 262K/16.7M |
| frekwensie | 60Hz |
| paneel gewig | 185g (Typ.) |
| sein koppelvlak | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C |
| paneel model | AC070MR11 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 154.4(W)×93.44(H) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | SWV, Normally Black, Transmissive |
| reaksie tyd | 15/15 (Typ.)(Tr/Td) |
| tipe lamp | 2 strings WLED , 50K hours , Without Driver |
| raakskerm | Without |
| aansoek | Industrial Outdoor High Brightness |
