| Onderdeel nommer | VVX07H005A10 |
| Handelsmerk | Panasonic |
| Grootte | 7.0 |
| Toepassing | PAD |
| Resolusie | 800×1280 |
| Samestelling | LCM |
| Helderheid | 450 |
| CR | 1000:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | MIPI |
| paneel handelsmerk | Panasonic |
| paneel model | VVX07H005A10 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 7.0 inch |
| resolusie | 800(RGB)×1280 , WXGA |
| vertoonmodus | IPS, Normally Black, Transmissive |
| aktiewe area | 94.2×150.72 mm |
| buitelyn | 104.32×161.67×3.6 mm |
| oppervlak | Hard coating |
| helderheid | 450 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) |
| kleure vertoon | 262K (6-bit), CIE193160% |
| reaksie tyd | 30 (Max.)(Tr+Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 5S5PWLEDWithout Driver |
| sein koppelvlak | MIPI (4 data lanes), 34 pins |
| insetspanning | 3.3/1.8V(Typ.) (VDD/VCC) |
| aansoek | PAD |
