| Onderdeel nommer | WF57STIACDNT0 |
| Handelsmerk | Winstar |
| Grootte | 5.7 |
| Toepassing | Industrial |
| Resolusie | 320×240 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleure | Grayscale |
| Agterlig | WLED |
| Koppelvlak | 8/16-bit |
| vervaardiger | Winstar |
| model naam | WF57STIACDNT0 |
| skerm grootte | 5.7 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 320×240 (QVGA) 70PPI |
| reëling | Rectangle |
| aktiewe area (mm) | 115.2 × 86.4 (H×V) |
| buitelyn (mm) | 160 × 109 × 9 (H×V×D) |
| ring area (mm) | 118.2 × 87.4 (H×V) |
| behandeling | Antiglare |
| helderheid | 700 cd/m² (Typ.) |
| kontras verhouding | 800 : 1 (Typ.) (TM) |
| kykhoek | - |
| reaksie | - |
| goeie uitsig by | 12 o'clock |
| werksmodus | TN, Normally White, Transmissive |
| kleurdiepte | Grayscale |
| agterlig | WLED , No Driver |
| massa | - |
| gebruik vir | Industrial |
| herlaaitempo | - |
| raakskerm | 4-wire Resistive Touch |
| sein tipe | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , FPC 22 pins |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AA057VF12 | Mitsubishi | 5.7 | 640×480 |
| AM-640480G2TNQW-00H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| AM-640480GFTNQW-T01H-L | AMPIRE | 5.7 | 640×480 |
| C555001 | SII | 5.7 | 320×240 |
| CLAA057VC01CT | CPT | 5.7 | 640×480 |
| EL320.240.36 | Lumineq | 5.7 | 320×240 |
| NL6448BC18-01F | NLT | 5.7 | 640×480 |
| SP14Q002-A1 | KOE | 5.7 | 320×240 |
| TM057KDH02 | Tianma | 5.7 | 320×240 |
