| Onderdeel nommer | WF57STIACDNN0 |
| Handelsmerk | Winstar |
| Grootte | 5.7 |
| Toepassing | Industrial |
| Resolusie | 320×240 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | Grayscale |
| Agterlig | WLED |
| Koppelvlak | 8/16-bit |
| paneel handelsmerk | Winstar |
| paneel grootte | 5.7" |
| resolusie | 320×240, QVGA, 70PPI |
| vertoon area | 115.2(W)×86.4(H) mm |
| omtrek grootte | 160(W)×109(H) ×7.5(D) mm |
| helderheid | 1000 cd/m² (Typ.) |
| kykhoek | - |
| beste uitsig op | 12 o'clock |
| kleure vertoon | Grayscale |
| frekwensie | - |
| paneel gewig | - |
| sein koppelvlak | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , 22 pins FPC |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| paneel model | WF57STIACDNN0 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | Rectangle |
| ring opening | 122.0(W)×92.0(H) mm |
| oppervlak | Glare (Haze 0%) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | - |
| tipe lamp | WLED , Without Driver |
| raakskerm | Without |
| aansoek | Industrial |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| G057VGE-T01 | Innolux | 5.7 | 640×480 |
| G057VN01 V0 | AUO | 5.7 | 640×480 |
| KG057QV1CA-G04 | Kyocera | 5.7 | 320×240 |
| KG057QV1DB-G00 | Kyocera | 5.7 | 320×240 |
| LTA057A341F | TOSHIBA | 5.7 | 320×240 |
| LTA057A344F | TOSHIBA | 5.7 | 320×240 |
| NL6448BC18-01 | NLT | 5.7 | 640×480 |
| SP14Q002-A1 | KOE | 5.7 | 320×240 |
| TX14D12VM1CBA | KOE | 5.7 | 320×240 |
