| Onderdeel nommer | WEH002004BR |
| Handelsmerk | Winstar |
| Grootte | 2.9 |
| Toepassing | Instruments & Me |
| Resolusie | 20×47 |
| Samestelling | PM-OLED, OLED |
| Helderheid | |
| CR | |
| Kleure | Mono(Red) |
| Agterlig | self |
| Koppelvlak | CPU/SPI |
| paneel handelsmerk | Winstar |
| paneel model | WEH002004BR |
| paneel grootte | 2.9" |
| paneel tipe | PM-OLED, OLED |
| vertoon formaat | 20 characters × 4 lines, 7PPI |
| lettertipe formaat | 5×8 dots |
| karakter grootte | 2.9×4.75(W×H) mm |
| karakter toonhoogte | 3.54×5.4(W×H) mm |
| vertoon area | 70.16(W)×20.95(H) mm |
| ring opening | 77(W)×25.2(H) mm |
| omtrek grootte | 98(W)×60(H) ×10(D) mm |
| oppervlak | - |
| kykhoek | - |
| vertoonmodus | - |
| beste uitsig op | Symmetry |
| reaksie tyd | - |
| kleure vertoon | Mono(Red) |
| tipe lamp | self |
| frekwensie | - |
| raakskerm | Without |
| bestuurder ic | COBBuilt-in WS0010 |
| paneel gewig | - |
| aansoek | Instruments & Meters |
| sein koppelvlak | CPU/SPI , 16 pins FPC |
| insetspanning | 5.0V (Typ.) |
