| Onderdeel nommer | WEA012864DLPP3N00003 |
| Handelsmerk | Winstar |
| Grootte | 0.96 |
| Toepassing | Instruments & Meters |
| Resolusie | 128×64 |
| Samestelling | OLED , PM-OLED |
| Helderheid | |
| CR | |
| Kleure | Mono(Yellow) |
| Agterlig | self |
| Koppelvlak | 4-wire |
| vervaardiger | Winstar |
| skerm grootte | 0.96 inch |
| pixel nommer | 128×64 149PPI |
| aktiewe area (mm) | 21.74 × 10.86 (H×V) |
| ring area (mm) | 23.94 × 12.06 (H×V) |
| kykhoek | - |
| goeie uitsig by | Symmetry |
| kleurdiepte | Mono(Yellow) |
| massa | - |
| herlaaitempo | - |
| bestuurder ic lys | Built-in COG SSD1306BZ |
| sein tipe | 4-wire SPI, I²C , 8 pins PIN |
| spanningstoevoer | 3.3/5.0/7.5V (Typ.) |
| maks. graderings | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 80 °C |
| model naam | WEA012864DLPP3N00003 |
| tipe skerm | OLED , PM-OLED |
| reëling | Rectangle |
| buitelyn (mm) | 38 × 28.5 × 4.37 (H×V×D) |
| behandeling | - |
| reaksie | - |
| werksmodus | - |
| agterlig | self |
| gebruik vir | Instruments & Meters |
| raakskerm | Without |
