| Onderdeel nommer | V850DK1-Q02 |
| Handelsmerk | Innolux |
| Grootte | 85 |
| Toepassing | TV Sets |
| Resolusie | 3840×2160 |
| Samestelling | CELL, a-Si TFT-LCD |
| Helderheid | |
| CR | 5000:1 |
| Kleure | 1.07B |
| Agterlig | No |
| Koppelvlak | |
| vervaardiger | Innolux |
| model naam | V850DK1-Q02 |
| skerm grootte | 85 inch |
| tipe skerm | CELL, a-Si TFT-LCD |
| pixel nommer | 3840(RGB)×2160 (UHD) 52PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 1872 × 1053 (H×V) |
| buitelyn (mm) | - |
| ring area (mm) | - |
| behandeling | Antiglare (Haze 0.5%) |
| helderheid | 0 cd/m² |
| kontras verhouding | 5000 : 1 (Typ.) (TM) |
| kykhoek | 88/88/88/88 (Typ.)(CR≥20) |
| reaksie | 6.5 (Typ.)(G to G) ms |
| goeie uitsig by | Symmetry |
| werksmodus | Super MVA, Normally Black, Transmissive |
| glas dikte | - |
| deurlaatbaarheid | 5.07% (Typ.)(with Polarizer) |
| kleurdiepte | 1.07B 79% NTSC |
| agterlig | No B/L |
| massa | 6.10±0.31Kgs |
| gebruik vir | TV Sets |
| herlaaitempo | 120Hz |
| raakskerm | Without |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
