| Onderdeel nommer | V750DK2-Q01 |
| Handelsmerk | Innolux |
| Grootte | 75 |
| Toepassing | TV Sets |
| Resolusie | 3840×2160 |
| Samestelling | CELL, a-Si TFT-LCD |
| Helderheid | |
| CR | 5000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | |
| vervaardiger | Innolux |
| model naam | V750DK2-Q01 |
| skerm grootte | 75 inch |
| tipe skerm | CELL, a-Si TFT-LCD |
| pixel nommer | 3840(RGB)×2160 (UHD) 59PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 1650.24 × 928.26 (H×V) |
| buitelyn (mm) | 1662.24 × 941.96 × 1.32 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare (Haze 1%), Hard coating (3H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 5000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 6.5 (Typ.)(G to G) ms |
| goeie uitsig by | Symmetry |
| werksmodus | Super MVA, Normally Black, Transmissive |
| glas dikte | - |
| deurlaatbaarheid | 5.0% (Typ.)(with Polarizer) |
| kleurdiepte | 16.7M 72% NTSC |
| agterlig | No B/L |
| massa | 4.62±0.23Kgs |
| gebruik vir | TV Sets |
| herlaaitempo | - |
| raakskerm | Without |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
