| Onderdeel nommer | V750DK1-QS3 Rev.P2 |
| Handelsmerk | Innolux |
| Grootte | 75 |
| Toepassing | TV Sets |
| Resolusie | 3840×2160 |
| Samestelling | a-Si TFT-LCD , CELL |
| Helderheid | |
| CR | 5000:1 |
| Kleure | 1.07B |
| Agterlig | No |
| Koppelvlak | V-by-One |
| handelsmerk | Innolux |
| diagonale grootte | 75 inch |
| pixel formaat | 3840(RGB)×2160 [UHD] 59PPI |
| aktiewe area | 1650.24(H)×928.26(V) mm |
| ring area | - |
| helderheid | 0 cd/m² |
| kyk rigting | Symmetry |
| kykhoek | 88/88/88/88 (Typ.)(CR≥10) |
| plaat dikte | 0.50+0.50 mm |
| ondersteun kleur | 1.07B 71% NTSC |
| gewig | 4.87±0.25Kgs (Typ.) |
| raamkoers | 120Hz |
| d-ic detail | COF Built-in 24 source + 16 gate chips |
| koppelvlak tipe | V-by-One 8 lane , 56 pins Connector |
| kragtoevoer | 12.0V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | V750DK1-QS3 Rev.P2 |
| tipe | a-Si TFT-LCD , CELL |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 1662.24(H)×941.96(V) ×1.32(D) mm |
| behandeling | Clear, Hard coating (3H), Reflection 1.8% (Typ.) |
| kontras verhouding | 5000:1 (Typ.) (TM) |
| reaksie tyd | 6.5 (Typ.)(G to G) |
| bedryfsmodus | Super MVA, Normally Black, Transmissive |
| oordrag | 5.0% (Typ.)(with Polarizer) |
| Ligbron | No B/L |
| ontwerp vir | TV Sets |
| raakpaneel | Without |
