| Onderdeel nommer | V750DJ3-Q01 |
| Handelsmerk | Innolux |
| Grootte | 75 |
| Toepassing | TV Sets |
| Resolusie | 3840×2160 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 5000:1 |
| Kleure | 1.07B |
| Agterlig | No |
| Koppelvlak | V-by-One |
| paneel handelsmerk | Innolux |
| paneel model | V750DJ3-Q01 |
| paneel grootte | 75" |
| paneel tipe | a-Si TFT-LCD, CELL |
| resolusie | 3840(RGB)×2160, UHD, 59PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 1650.24(W)×928.26(H) mm |
| ring opening | - |
| omtrek grootte | 1662.24(W)×941.96(H) ×1.33(D) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 5000:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| vertoonmodus | Super MVA, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 9.5 (Typ.)(G to G) |
| glas diepte | 0.50+0.50 mm |
| deurlaatbaarheid | 5.4% (Typ.)(with Polarizer) |
| kleure vertoon | 1.07B 72% NTSC |
| tipe lamp | No B/L |
| frekwensie | 60Hz |
| raakskerm | Without |
| bestuurder ic | COFBuilt-in 12 source chips |
| paneel gewig | 4.50±0.14Kgs |
| aansoek | TV Sets |
| sein koppelvlak | V-by-One 8 lane , 51 pins Connector |
| insetspanning | 12.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
