| Onderdeel nommer | V450HJ1-Q01 Rev.C1 |
| Handelsmerk | Innolux |
| Grootte | 44.5 |
| Toepassing | TV Sets |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 4800:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | LVDS |
| paneel handelsmerk | Innolux |
| paneel model | V450HJ1-Q01 Rev.C1 |
| paneel grootte | 44.5" |
| paneel tipe | a-Si TFT-LCD, CELL |
| resolusie | 1920(RGB)×1080, FHD, 49PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 989.568(W)×546.264(H) mm |
| ring opening | - |
| omtrek grootte | 999.568(W)×556.364(H) ×1.3(D) mm |
| oppervlak | Antiglare (Haze 1%) |
| helderheid | 0 cd/m² |
| kontras verhouding | 4800:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| vertoonmodus | Super MVA, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 9.5 (Typ.)(G to G) |
| glas diepte | - |
| deurlaatbaarheid | 5.35% (Typ.)(with Polarizer) |
| kleure vertoon | 16.7M 70% NTSC |
| tipe lamp | No B/L |
| frekwensie | 60Hz |
| raakskerm | Without |
| bestuurder ic | COFBuilt-in 8 source + 4 gate chips |
| paneel gewig | 1.64±0.08Kgs |
| aansoek | TV Sets |
| sein koppelvlak | LVDS (2 ch, 8-bit) , 51 pins Connector |
| insetspanning | 12.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C |
