| Onderdeel nommer | V420HK1-LS5 |
| Handelsmerk | Innolux |
| Grootte | 42 |
| Toepassing | LCTV |
| Resolusie | 1920×1080 |
| Samestelling | LCM |
| Helderheid | 400 |
| CR | 5000:1 |
| Kleure | 1.07B |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | CHIMEI INNOLUX |
| paneel model | V420HK1-LS5 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 42 inch |
| resolusie | 1920(RGB)×1080 , FHD |
| vertoonmodus | Super MVA, Normally Black, Transmissive |
| aktiewe area | 930.24×523.26 mm |
| buitelyn | 958.2×553.3 mm |
| oppervlak | Antiglare (Haze 3.5%), Hard coating (3H) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 5000:1 (Typ.) |
| kleure vertoon | 1.07B (8-bit + Hi-FRC), CIE193172% |
| reaksie tyd | 6 (Typ.)(G to G) |
| kykhoek | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekwensie | 120Hz |
| tipe lamp | WLEDEmbedded (LED Driver) |
| sein koppelvlak | LVDS (4 ch, 10-bit), 92 pins |
| insetspanning | 12.0V (Typ.) |
| aansoek | LCTV |
| V420H1-LE1 | Innolux | 42 | 1920×1080 |
| V420H1-LH4 | Innolux | 42 | 1920×1080 |
| V420H1-LH5 | Innolux | 42 | 1920×1080 |
| V420H2-L01 | Innolux | 42 | 1920×1080 |
| V420H2-LE3 | Innolux | 42 | 1920×1080 |
| V420H2-LN1 | Innolux | 42 | 1920×1080 |
| V420H2-LS1 | Innolux | 42 | 1920×1080 |
| V420HJ2-P01 | Innolux | 42 | 1920×1080 |
| V420HK1-LS5 | Innolux | 42 | 1920×1080 |
| V420HK1-LS5 Rev.C7 | Innolux | 42 | 1920×1080 |
| LC550EQN-PGF1 | LG Display | 55 | 3840×2160 |
| LC650EQD-FGF4 | LG Display | 65 | 3840×2160 |
| LSC460HN03-W | Samsung | 46 | 1920×1080 |
| LTA260W2-L12 | Samsung | 26.0 | 1366×768 |
| ST3151A05-8 | CSOT | 31.5 | 1366×768 |
| T260XW02 V5 | AUO | 26.0 | 1366×768 |
| T500HVN05.0 CELL | AUO | 50 | 1920×1080 |
| T650HVN04.1 | AUO | 65 | 1920×1080 |
| V260H1-LE2 | Innolux | 26.0 | 1920×1080 |
| V420H1-L15 | Innolux | 42 | 1920×1080 |
