V315B5-LE3

V315B5-LE3
V315B5-LE3
V315B5-LE3 thumb V315B5-LE3 thumb
Handelsmerk
Innolux
Grootte
31.5
Toepassing
LCTV
Resolusie
1366×768
Samestelling
LCM
Helderheid
400
CR
5000:1
Kleure
16.7M
Agterlig
WLED
Koppelvlak
LVDS
In Stock
3272
Spesifikasies

Onderdeel nommer V315B5-LE3
HandelsmerkInnolux
Grootte31.5
ToepassingLCTV
Resolusie1366×768
SamestellingLCM
Helderheid400
CR5000:1
Kleure16.7M
AgterligWLED
KoppelvlakLVDS
paneel handelsmerkCHIMEI INNOLUX
paneel modelV315B5-LE3
paneel tipe a-Si TFT-LCD , LCM
paneel grootte31.5 inch
resolusie1366(RGB)×768 , WXGA
vertoonmodusSuper MVA, Normally Black, Transmissive
aktiewe area697.685×392.256 mm
buitelyn735.4×433 mm
oppervlakAntiglare (Haze 11%), Hard coating (3H)
helderheid400 cd/m² (Typ.)
kontras verhouding5000:1 (Typ.)
kleure vertoon16.7M (8-bit), CIE193172%
reaksie tyd8.5 (Typ.)(Tr+Td)
kykhoek88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
frekwensie60Hz
tipe lampWLEDEmbedded (LED Driver)
sein koppelvlakLVDS (1 ch, 8-bit), 30 pins
insetspanning12.0V (Typ.)
aansoekLCTV
Familie Model
V315B1-L01 Innolux 31.5 1366×768
V315B3-L04 Innolux 31.5 1366×768
V315B5-L01 Innolux 31.5 1366×768
V315B5-L02 Innolux 31.5 1366×768
V315B5-L03 Innolux 31.5 1366×768
V315B5-L06 Innolux 31.5 1366×768
V315B5-LE3 Innolux 31.5 1366×768
V315B6-L02 Innolux 31.5 1366×768
V315B6-L03 Innolux 31.5 1366×768
V315B6-L04 Innolux 31.5 1366×768
