| Onderdeel nommer | UG-6464TDDBG01 |
| Handelsmerk | WiseChip |
| Grootte | 0.60 |
| Toepassing | - |
| Resolusie | 64×64 |
| Samestelling | PM-OLED , OLED |
| Helderheid | |
| CR | 10000:1 |
| Kleure | 65K |
| Agterlig | self |
| Koppelvlak | 4-wire |
| paneel handelsmerk | WiseChip |
| paneel grootte | 0.60" |
| resolusie | 64(RGB)×64, 151PPI |
| vertoon area | 10.73(W)×10.73(H) mm |
| omtrek grootte | 15(W)×17.5(H) ×1.3(D) mm |
| helderheid | 200 cd/m² (Typ.) |
| kykhoek | - |
| beste uitsig op | Symmetry |
| kleure vertoon | 65K 60% NTSC |
| frekwensie | - |
| bestuurder ic | COG Built-in SSD1357 |
| paneel gewig | 0.66±0.06g |
| sein koppelvlak | 4-wire SPI , 20 pins FPC |
| insetspanning | 3.0/12.0V (Typ.)(VDD/VCC) |
| omgewing | Operating Temp.: -40 ~ 70 °C ; Storage Temp.: -40 ~ 85 °C |
| paneel model | UG-6464TDDBG01 |
| paneel tipe | PM-OLED , OLED |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 11.73(W)×11.73(H) mm |
| oppervlak | - |
| kontras verhouding | 10000:1 (Typ.) (TM) |
| vertoonmodus | - |
| reaksie tyd | - |
| tipe lamp | self , 10K hours |
| raakskerm | Without |
| aansoek |
