| Onderdeel nommer | UG-2828GDEDF15 |
| Handelsmerk | Univision |
| Grootte | 1.5 |
| Toepassing | Mobile Phone Handhel |
| Resolusie | 128×128 |
| Samestelling | PM-OLED, OLED |
| Helderheid | |
| CR | 2000:1 |
| Kleure | 262K |
| Agterlig | self |
| Koppelvlak | 8-bit |
| handelsmerk | Univision |
| model | UG-2828GDEDF15 |
| diagonale grootte | 1.5 inch |
| tipe | PM-OLED, OLED |
| pixel formaat | 128(RGB)×128 121PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 26.855(H)×26.864(V) mm |
| buitelyn dof. | 33.8(H)×34(V) ×1.7(D) mm |
| ring area | 28.855(H)×28.864(V) mm |
| behandeling | - |
| helderheid | 90 cd/m² (Typ.) |
| kontras verhouding | 2000:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | - |
| kykhoek | 80/80/80/80 (Min.) |
| bedryfsmodus | - |
| ondersteun kleur | 262K |
| Ligbron | self , 20K hours |
| gewig | 3.80g (Typ.) |
| ontwerp vir | Mobile Phone Handheld & PDA |
| raamkoers | - |
| raakpaneel | Without |
| d-ic detail | COF Built-in SSD1351 |
| koppelvlak tipe | 8-bit 6800/8080 parallel, 3/4-wire SPI , 30 pins FPC |
| kragtoevoer | 2.8/2.5/1.8/13V (Typ.)(VCI/VDD/VDDIO/VCC) |
| omgewing | Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -40 ~ 80 °C |
