| Onderdeel nommer | TX54D31VC0CAB |
| Handelsmerk | KOE |
| Grootte | 21.3 |
| Toepassing | Industrial |
| Resolusie | 1600×1200 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleure | 16.7M |
| Agterlig | 6 |
| Koppelvlak | LVDS |
| vervaardiger | KOE |
| model naam | TX54D31VC0CAB |
| skerm grootte | 21.3 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 1600(RGB)×1200 (UXGA) 94PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 432 × 324 (H×V) |
| buitelyn (mm) | 460.6 × 362 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare |
| helderheid | 450 cd/m² (Typ.) |
| kontras verhouding | 500 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 15/10 (Typ.)(Tr/Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS, Normally Black, Transmissive |
| kleurdiepte | 16.7M |
| agterlig | 6 pcs CCFL |
| massa | 2.700/3.00Kgs (Typ./Max.) |
| gebruik vir | Industrial |
| herlaaitempo | - |
| raakskerm | Without |
| sein tipe | LVDS (2 ch, 8-bit) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| G213QAN01.0 | AUO | 21.3 | 2048×1536 |
| LTM213U4-L01 | Samsung | 21.3 | 1600×1200 |
| LTM213U6-L01 | Samsung | 21.3 | 1600×1200 |
| NL160120BC27-14 | NLT | 21.3 | 1600×1200 |
| NL160120BM27-03A | NLT | 21.3 | 1600×1200 |
| NL160120BM27-07 | NLT | 21.3 | 1600×1200 |
| NL204153AC21-22 | NLT | 21.3 | 2048×1536 |
| NL204153BM21-04A | NLT | 21.3 | 2048×1536 |
| R213RFE-L01 | Innolux | 21.3 | 2048×1536 |
| R213T3-L02 | Innolux | 21.3 | 2560×2048 |
