| Onderdeel nommer | TX43D14VC0CAB |
| Handelsmerk | KOE |
| Grootte | 17.0 |
| Toepassing | DMPC |
| Resolusie | 1280×1024 |
| Samestelling | LCM |
| Helderheid | 230 |
| CR | 400:1 |
| Kleure | 16.7M |
| Agterlig | CCFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | HITACHI |
| paneel model | TX43D14VC0CAB |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 17.0 inch |
| resolusie | 1280(RGB)×1024 , SXGA |
| vertoonmodus | IPS-Pro, Normally Black, Transmissive |
| aktiewe area | 337.92×270.336 mm |
| buitelyn | 368×306 mm |
| oppervlak | Antiglare |
| helderheid | 230 cd/m² (Typ.) |
| kontras verhouding | 400:1 (Typ.) |
| kleure vertoon | 16.7M (6-bit + Hi-FRC) |
| reaksie tyd | 20/20 (Typ.)(Tr/Td) |
| kykhoek | |
| frekwensie | 60Hz |
| tipe lamp | 4 pcsCCFLWithout Driver |
| sein koppelvlak | LVDS (2 ch, 8-bit), 30 pins |
| insetspanning | 5.0V (Typ.) |
| aansoek | DMPC |
