| Onderdeel nommer | TX39D80VC1GAA |
| Handelsmerk | KOE |
| Grootte | 15.4 |
| Toepassing | NBPC |
| Resolusie | 1280×800 |
| Samestelling | LCM |
| Helderheid | 480 |
| CR | 600:1 |
| Kleure | 262K |
| Agterlig | CCFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | HITACHI |
| paneel model | TX39D80VC1GAA |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 15.4 inch |
| resolusie | 1280(RGB)×800 , WXGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 331.2×207 mm |
| buitelyn | 344×225 mm |
| oppervlak | Glare (Haze 0%) |
| helderheid | 480 cd/m² (Typ.) |
| kontras verhouding | 600:1 (Min.) |
| kleure vertoon | 262K (6-bit) |
| reaksie tyd | 50 (Typ.)(Tr+Td) |
| kykhoek | |
| frekwensie | 60Hz |
| tipe lamp | 2 pcsCCFLWithout Driver |
| sein koppelvlak | LVDS (1 ch, 6-bit) |
| insetspanning | 3.3V (Typ.) |
| rohs: | |
| aansoek | NBPC |
