| Onderdeel nommer | TX26D207VM0AAA |
| Handelsmerk | KOE |
| Grootte | 10.1 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1280×800 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1500:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | KOE |
| diagonale grootte | 10.1 inch |
| pixel formaat | 1280(RGB)×800 [WXGA] 149PPI |
| aktiewe area | 217.344(H)×135.84(V) mm |
| ring area | 220.344(H)×138.838(V) mm |
| helderheid | 1000 cd/m² (Typ.) |
| kyk rigting | Symmetry |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| ondersteun kleur | 16.7M 65% NTSC |
| gewig | 340g (Typ.) |
| raamkoers | 60Hz |
| koppelvlak tipe | LVDS (1 ch, 8-bit) , 20 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| model | TX26D207VM0AAA |
| tipe | a-Si TFT-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 231(H)×153.5(V) ×11.07(D) mm |
| behandeling | - |
| kontras verhouding | 1500:1 (Typ.) (TM) |
| reaksie tyd | 25 (Max.)(Tr+Tf) |
| bedryfsmodus | IPS, Normally Black, Transmissive |
| Ligbron | WLED , 70K hours , With LED Driver |
| ontwerp vir | Industrial Outdoor High Brightness Automotive Display |
| raakpaneel | Without |
