| Onderdeel nommer | TX18D211VM0BAA |
| Handelsmerk | KOE |
| Grootte | 7.0 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 800×480 |
| Samestelling | LTPS TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | KOE |
| paneel model | TX18D211VM0BAA |
| paneel grootte | 7.0" |
| paneel tipe | LTPS TFT-LCD, LCM |
| resolusie | 800(RGB)×480, WVGA, 133PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 152.4(W)×91.44(H) mm |
| ring opening | 156.2(W)×94.5(H) mm |
| omtrek grootte | 167.7(W)×109.5(H) ×20.3(D) mm |
| oppervlak | - |
| helderheid | 1200 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kleure vertoon | 262K 73% NTSC |
| tipe lamp | WLED , 50K hours , With LED Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | 219g (Typ.) |
| aansoek | Industrial Outdoor High Brightness Automotive Display |
| sein koppelvlak | LVDS (1 ch, 6-bit) , 20 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| AT070TN07 V.D | Innolux | 7.0 | 480×234 |
| C070VW02 V1 | AUO | 7.0 | 800×480 |
| CLAA070LF06CW | CPT | 7.0 | 800×480 |
| LA070WV1-TD03 | LG Display | 7.0 | 800×480 |
| LMS700KF01-001 | Samsung | 7.0 | 800×480 |
| LQ070T5BG01 | SHARP | 7.0 | 480×234 |
| LQ070Y3LW01 | SHARP | 7.0 | 800×480 |
| LR700BA9005 | Innolux | 7.0 | 480×234 |
| LW700AT9008 | Innolux | 7.0 | 800×480 |
| TX18D37VM0ARA | KOE | 7.0 | 800×480 |
