| Onderdeel nommer | TX16D204VM0BAA |
| Handelsmerk | KOE |
| Grootte | 6.3 |
| Toepassing | Industrial |
| Resolusie | 800×280 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 262K |
| Agterlig | 3S3P |
| Koppelvlak | CMOS |
| paneel handelsmerk | KOE |
| paneel grootte | 6.3" |
| resolusie | 800(RGB)×280, 135PPI |
| vertoon area | 150(W)×52.5(H) mm |
| omtrek grootte | 167(W)×69(H) ×9.5(D) mm |
| helderheid | 500 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 262K 52% NTSC |
| frekwensie | 60Hz |
| paneel gewig | 107g (Typ.) |
| sein koppelvlak | CMOS (1 ch, 6-bit) , 50 pins FPC |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| paneel model | TX16D204VM0BAA |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 153(W)×55.5(H) mm |
| oppervlak | - |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| reaksie tyd | 40 (Typ.)(Tr+Td) |
| tipe lamp | 3S3P WLED , 50K hours , Without Driver |
| raakskerm | Without |
| aansoek | Industrial |
