| Onderdeel nommer | TV156FHM-NH2 |
| Handelsmerk | BOE |
| Grootte | 15.6 |
| Toepassing | Laptop |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | eDP |
| handelsmerk | BOE |
| diagonale grootte | 15.6 inch |
| pixel formaat | 1920(RGB)×1080 [FHD] 141PPI |
| aktiewe area | 344.16(H)×193.59(V) mm |
| ring area | - |
| helderheid | 300 cd/m² (Typ.) |
| kyk rigting | Symmetry |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| ondersteun kleur | 262K 72% NTSC |
| vorm styl | Slim (PCBA Flat, T≤3.2mm) |
| raamkoers | 60Hz |
| koppelvlak tipe | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | TV156FHM-NH2 (BOE0936) |
| tipe | a-Si TFT-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 350.66(H)×215.75(V) ×3.2(D) mm |
| behandeling | Antiglare, Hard coating (3H) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| bedryfsmodus | IPS, Normally Black, Transmissive |
| Ligbron | WLED [11S5P] , 15K hours , With LED Driver |
| ontwerp vir | Laptop |
| raakpaneel | Without |
| B156HB01 V0 | AUO | 15.6 | 1920×1080 |
| B156HW01 V4 | AUO | 15.6 | 1920×1080 |
| B156XTN04.1 | AUO | 15.6 | 1366×768 |
| B156XW01 V2 | AUO | 15.6 | 1366×768 |
| LP156WD1-TPB1 | LG Display | 15.6 | 1600×900 |
| LP156WHB-TPD1 | LG Display | 15.6 | 1366×768 |
| LTN156AT05-J08 | Samsung | 15.6 | 1366×768 |
| LTN156AT24-P01 | Samsung | 15.6 | 1366×768 |
| N156BGE-E21 | Innolux | 15.6 | 1366×768 |
| NV156FHM-N42 | BOE | 15.6 | 1920×1080 |
