| Onderdeel nommer | TV122WXM-NW0 |
| Handelsmerk | BOE |
| Grootte | 12.2 |
| Toepassing | NBPC |
| Resolusie | 1280×800 |
| Samestelling | LCM |
| Helderheid | 300 |
| CR | 900:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| paneel handelsmerk | BOE |
| paneel model | TV122WXM-NW0 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 12.2 inch |
| resolusie | 1280(RGB)×800 , WXGA |
| vertoonmodus | ADS, Normally Black, Transmissive |
| aktiewe area | 262.565×164.16 mm |
| buitelyn | 271.06×176.42×2.86 mm |
| oppervlak | |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 900:1 (Typ.) |
| kleure vertoon | 16.7M (8-bit), CIE193150% |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | WLEDWithout Driver |
| sein koppelvlak | eDP (2 Lanes), 39 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | NBPC |
| TV122WXM-NW0 | BOE | 12.2 | 1280×800 |
| TX31D16VM2BAA | KOE | 12.2 | 1024×310 |
| B173HTN01.1 | AUO | 17.3 | 1920×1080 |
| LP140WH1-TLD2 | LG Display | 14.0 | 1366×768 |
| LTN133AT17-W01 | Samsung | 13.3 | 1366×768 |
| LTN133AT27-102 | Samsung | 13.3 | 1366×768 |
| LTN140AT20-401 | Samsung | 14.0 | 1366×768 |
| LTN156AT35-W01 | Samsung | 15.6 | 1366×768 |
| LTN160AT04-N01 | Samsung | 16.0 | 1366×768 |
| N101BGE-L21 | Innolux | 10.1 | 1366×768 |
| N121IB-L05 Rev.C1 | Innolux | 12.1 | 1280×800 |
| N156BGE-E11 | Innolux | 15.6 | 1366×768 |
