| Onderdeel nommer | TV105WUM-AS0 |
| Handelsmerk | BOE |
| Grootte | 10.5 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | Assembly , a-Si TF |
| Helderheid | |
| CR | 900:1 |
| Kleure | 16.7M |
| Agterlig | 4 |
| Koppelvlak | MIPI |
| vervaardiger | BOE |
| skerm grootte | 10.5 inch |
| pixel nommer | 1200(RGB)×1920 (WUXGA) 215PPI |
| aktiewe area (mm) | 141.3 × 226.08 (H×V) |
| ring area (mm) | - |
| helderheid | 480 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 16.7M 92% DCI-P3 |
| massa | 216g (Typ.) |
| herlaaitempo | 60Hz |
| sein tipe | MIPI (4 data lanes) , 34 pins Connector |
| spanningstoevoer | 1.8/5.8/-5.8V (Typ.)(VDD/VSP/VSN) |
| maks. graderings | Storage Temp.: -55 ~ 125 °C Operating Temp.: -20 ~ 85 °C |
| model naam | TV105WUM-AS0 |
| tipe skerm | Assembly , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 156.18 × 255.06 × 4.44 (H×V×D) |
| behandeling | Hard coating |
| kontras verhouding | 900 : 1 (Typ.) (TM) |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| werksmodus | - |
| agterlig | 4 strings WLED , No Driver |
| gebruik vir | Pad & Tablet |
| raakskerm | PCAP |
