| Onderdeel nommer | TV101WXM-NU5 |
| Handelsmerk | BOE |
| Grootte | 10.1 |
| Toepassing | Pad & Tablet |
| Resolusie | 800×1280 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 7S4P |
| Koppelvlak | |
| vervaardiger | BOE |
| skerm grootte | 10.1 inch |
| pixel nommer | 800(RGB)×1280 (WXGA) 150PPI |
| aktiewe area (mm) | 135.36 × 216.576 (H×V) |
| ring area (mm) | 137.76 × 220.076 (H×V) |
| helderheid | 400 (Typ.)(cd/m²) |
| kykhoek | 85/85/85/85 (Min.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 16.7M 60% NTSC |
| massa | 135g (Max.) |
| herlaaitempo | 60Hz |
| model naam | TV101WXM-NU5 |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 142.32 × 228.2 × 4.3 (H×V×D) |
| behandeling | - |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| werksmodus | ADS, Normally Black, Transmissive |
| reaksie | 30 (Typ.)(Tr+Td) ms |
| agterlig | 7S4P WLED , No Driver |
| gebruik vir | Pad & Tablet |
| raakskerm | Without |
| A101VW01 V1 | AUO | 10.1 | 800×480 |
| CLAA101WJ06 | CPT | 10.1 | 1366×768 |
| G101ICE-L01 | Innolux | 10.1 | 1280×800 |
| HSD101PFW2-C00 | HannStar | 10.1 | 1024×600 |
| LP101WH1-TLB5 | LG Display | 10.1 | 1366×768 |
| N101L6-L0A | Innolux | 10.1 | 1024×600 |
| P101KDA-AP1 | Innolux | 10.1 | 1200×1920 |
| TV101WUM-NH0 | BOE | 10.1 | 1200×1920 |
| TV101WXM-NP0 | BOE | 10.1 | 1280×800 |
| TV101WXM-NP1 | BOE | 10.1 | 1280×800 |
