| Onderdeel nommer | TV101WUM-NW1 |
| Handelsmerk | No Brand |
| Grootte | 10.1 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 8S4P |
| Koppelvlak | MIPI |
| paneel handelsmerk | No Brand |
| paneel grootte | 10.1" |
| resolusie | 1200(RGB)×1920, WUXGA, 225PPI |
| vertoon area | 135.36(W)×216.576(H) mm |
| omtrek grootte | 142.76(W)×228.18(H) ×4.2(D) mm |
| helderheid | 450 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 100% sRGB |
| frekwensie | 60Hz |
| paneel gewig | TBD |
| sein koppelvlak | MIPI (4 data lanes) , 40 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
| paneel model | TV101WUM-NW1 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Clear, Hard coating |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | HADS, Normally Black, Transmissive |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| tipe lamp | 8S4P WLED , Without Driver |
| raakskerm | Without |
| aansoek | Pad & Tablet |
| AM-1280800N2TZQW-T48H | AMPIRE | 10.1 | 1280×800 |
| B101EW01 V0 | AUO | 10.1 | 1280×720 |
| BT101IW02 V.0 | Innolux | 10.1 | 1024×600 |
| DLC1010DZG-T-8 | Other | 10.1 | 1280×800 |
| HSD100IFW1-A04 | HannStar | 10.1 | 1024×600 |
| HSD101PFW2-B00 | HannStar | 10.1 | 1024×600 |
| LP101WS1-TLB1 | LG Display | 10.1 | 1024×576 |
| TV101WUM-NH0 | BOE | 10.1 | 1200×1920 |
| TV101WXM-NP0 | BOE | 10.1 | 1280×800 |
| TV101WXM-NP1 | BOE | 10.1 | 1280×800 |
