| Onderdeel nommer | TV101WUM-NM1 |
| Handelsmerk | BOE |
| Grootte | 10.1 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 900:1 |
| Kleure | 16.7M |
| Agterlig | 8S4P |
| Koppelvlak | MIPI |
| vervaardiger | BOE |
| model naam | TV101WUM-NM1 |
| skerm grootte | 10.1 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 1200(RGB)×1920 (WUXGA) 225PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 135.36 × 216.576 (H×V) |
| buitelyn (mm) | 143 × 227.926 × 4.4 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare, Hard coating, Antireflection |
| helderheid | - |
| kontras verhouding | 900 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 30 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | ADS, Normally Black, Transmissive |
| kleurdiepte | 16.7M |
| agterlig | 8S4P WLED , 30K hours , No Driver |
| massa | 145g (Max.) |
| gebruik vir | Pad & Tablet |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | MIPI (4 data lanes) Connector |
| spanningstoevoer | 3.3V (Typ.)(VDD) |
| maks. graderings | Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
