| Onderdeel nommer | TV101WUM-NH1 |
| Handelsmerk | BOE |
| Grootte | 10.1 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | BOE |
| diagonale grootte | 10.1 inch |
| pixel formaat | 1200(RGB)×1920 [WUXGA] 225PPI |
| aktiewe area | 135.36(H)×216.576(V) mm |
| ring area | - |
| helderheid | 450 cd/m² (Typ.) |
| kyk rigting | Symmetry |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| ondersteun kleur | 16.7M 100% sRGB |
| gewig | 130g (Max.) |
| raamkoers | 60Hz |
| model | TV101WUM-NH1 |
| tipe | a-Si TFT-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 141.6(H)×227.41(V) ×3.8(D) mm |
| behandeling | Hard coating (3H) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| reaksie tyd | 25 (Typ.)(Tr+Tf) |
| bedryfsmodus | IPS, Normally Black, Transmissive |
| Ligbron | WLED [8S4P] , W/O Driver |
| ontwerp vir | Pad & Tablet |
| raakpaneel | Without |
| B101EVT05.0 | AUO | 10.1 | 1280×800 |
| HSD101PFW2-B00 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-H00 | HannStar | 10.1 | 1280×800 |
| LP101WH1-TLP1 | LG Display | 10.1 | 1366×768 |
| LTL101AL06-002 | Samsung | 10.1 | 1280×800 |
| M101NWWB R6 | IVO | 10.1 | 1280×800 |
| N101ICE-G63 | Innolux | 10.1 | 1280×800 |
| TV101WUM-NH0 | BOE | 10.1 | 1200×1920 |
| TV101WXM-NP0 | BOE | 10.1 | 1280×800 |
| TV101WXM-NP1 | BOE | 10.1 | 1280×800 |
