| Onderdeel nommer | TV101WUB-NV0 |
| Handelsmerk | BOE |
| Grootte | 10.1 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 900:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | MIPI |
| handelsmerk | BOE |
| model | TV101WUB-NV0 |
| diagonale grootte | 10.1 inch |
| tipe | a-Si TFT-LCD, CELL |
| pixel formaat | 1200(RGB)×1920 [WUXGA] 225PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 135.36(H)×216.576(V) mm |
| buitelyn dof. | 140.26(H)×225.346(V) ×0.8(D) mm |
| helderheid | 0 cd/m² |
| kontras verhouding | 900:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| bedryfsmodus | ADS, Normally Black, Transmissive |
| plaat dikte | 0.25+0.25 mm |
| oordrag | 5.1% (Typ.)(with Polarizer) |
| ondersteun kleur | 16.7M 71% NTSC |
| Ligbron | No B/L |
| gewig | - |
| ontwerp vir | Pad & Tablet |
| raamkoers | 60Hz |
| raakpaneel | Without |
| d-ic detail | COG Built-in 2 source chips |
| koppelvlak tipe | MIPI (4 data lanes) , 44 pins Connector |
| kragtoevoer | 3.3/9.8/4.8V (Typ.)(VDDI/AVDD/HAVDD) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
