| Onderdeel nommer | TV080WUM-TL1 |
| Handelsmerk | BOE |
| Grootte | 8.0 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | a-Si TFT-LCD, Assemb |
| Helderheid | |
| CR | 900:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | BOE |
| model | TV080WUM-TL1 |
| diagonale grootte | 8.0 inch |
| tipe | a-Si TFT-LCD, Assembly |
| pixel formaat | 1200(RGB)×1920 [WUXGA] 283PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 107.64(H)×172.224(V) mm |
| buitelyn dof. | 117.7(H)×193.84(V) ×5.5(D) mm |
| ring area | - |
| behandeling | Hard coating |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 900:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| bedryfsmodus | HADS, Normally Black, Transmissive |
| ondersteun kleur | 16.7M 58% NTSC |
| Ligbron | WLED [6S4P] , W/O Driver |
| gewig | 155g (Max.) |
| ontwerp vir | Pad & Tablet |
| raamkoers | 60Hz |
| raakpaneel | On-Cell Touch |
| Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
