| Onderdeel nommer | TV080WUM-TL0 |
| Handelsmerk | BOE |
| Grootte | 8.0 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | a-Si TFT-LCD , Assem |
| Helderheid | |
| CR | 900:1 |
| Kleure | 16.7M |
| Agterlig | 4 |
| Koppelvlak | |
| paneel handelsmerk | BOE |
| paneel grootte | 8.0" |
| resolusie | 1200(RGB)×1920, WUXGA, 283PPI |
| vertoon area | 107.64(W)×172.224(H) mm |
| omtrek grootte | 117.7(W)×193.28(H) ×5.5(D) mm |
| helderheid | 350 cd/m² (Typ.) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 58% NTSC |
| frekwensie | 60Hz |
| gewig | 150g (Max.) |
| paneel model | TV080WUM-TL0 |
| paneel tipe | a-Si TFT-LCD , Assembly |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Hard coating |
| kontras verhouding | 900:1 (Typ.) (TM) |
| vertoonmodus | - |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| tipe lamp | 4 strings WLED , Without Driver |
| raakskerm | On-Cell Touch |
| aansoek | Pad & Tablet |
