| Onderdeel nommer | TV080WUM-NX2 |
| Handelsmerk | BOE |
| Grootte | 8.0 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1200:1 |
| Kleure | 16.7M |
| Agterlig | 8S3P |
| Koppelvlak | |
| vervaardiger | BOE |
| skerm grootte | 8.0 inch |
| pixel nommer | 1200(RGB)×1920 (WUXGA) 283PPI |
| aktiewe area (mm) | 107.64 × 172.224 (H×V) |
| ring area (mm) | - |
| helderheid | 435 (Typ.)(cd/m²) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 16.7M 71% NTSC |
| massa | 95.0g (Max.) |
| herlaaitempo | 60Hz |
| model naam | TV080WUM-NX2 |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 113.14 × 182.424 × 2.35 (H×V×D) |
| behandeling | Hard coating |
| kontras verhouding | 1200 : 1 (Typ.) (TM) |
| werksmodus | ADS, Normally Black, Transmissive |
| reaksie | 35 (Max.)(Tr+Td) ms |
| agterlig | 8S3P WLED , No Driver |
| gebruik vir | Pad & Tablet |
| raakskerm | Without |
| A080XN01 V1 | AUO | 8.0 | 1024×768 |
| AT080TN42 V.1 | Innolux | 8.0 | 800×600 |
| CLAA080LB0AXV | CPT | 8.0 | 800×480 |
| L5F30614T65 | SANYO | 8.0 | 800×480 |
| LB080WV3-B1 | LG Display | 8.0 | 800×480 |
| P080KDZ-3Z1 | Innolux | 8.0 | 1200×1920 |
| PD080SL1 | E Ink | 8.0 | 800×600 |
| PD080SL2 | E Ink | 8.0 | 800×600 |
| PD080SY1 | E Ink | 8.0 | 800×600 |
| TV080WXM-NL0 | BOE | 8.0 | 800×1280 |
