| Onderdeel nommer | TV080WUM-NL1 |
| Handelsmerk | BOE |
| Grootte | 8.0 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 8S3P |
| Koppelvlak | MIPI |
| vervaardiger | BOE |
| model naam | TV080WUM-NL1 |
| skerm grootte | 8.0 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 1200(RGB)×1920 (WUXGA) 283PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 107.64 × 172.224 (H×V) |
| buitelyn (mm) | 114.6 × 183.75 × 3.75 (H×V×D) |
| ring area (mm) | - |
| behandeling | Hard coating |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | ADS, Normally Black, Transmissive |
| kleurdiepte | 16.7M 63% NTSC |
| agterlig | 8S3P WLED , 15K hours , No Driver |
| massa | 85.0g (Max.) |
| gebruik vir | Pad & Tablet |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | MIPI (4 data lanes) , 45 pins Connector |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -30 ~ 70 °C Operating Temp.: -20 ~ 60 °C |
| A080SN03 V0 | AUO | 8.0 | 800×600 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| DJ080PA-01C | Innolux | 8.0 | |
| LB080WV4-TD02 | LG Display | 8.0 | 800×480 |
| LM64C21P | SHARP | 8.0 | 640×480 |
| LM64P122 | SHARP | 8.0 | 640×480 |
| LT080EE04100 | TOSHIBA | 8.0 | 1600×768 |
| N080ICE-GB0 Rev.C2 | Innolux | 8.0 | 800×1280 |
| PD080SL2 | E Ink | 8.0 | 800×600 |
| TV080WXM-NL0 | BOE | 8.0 | 800×1280 |
