| Onderdeel nommer | TV080WUM-AK2 |
| Handelsmerk | BOE |
| Grootte | 8.0 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | Assembly , a-Si TF |
| Helderheid | |
| CR | 850:1 |
| Kleure | 16.7M |
| Agterlig | 7S3P |
| Koppelvlak | MIPI |
| vervaardiger | BOE |
| model naam | TV080WUM-AK2 |
| skerm grootte | 8.0 inch |
| tipe skerm | Assembly , a-Si TFT-LCD |
| pixel nommer | 1200(RGB)×1920 (WUXGA) 283PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 107.64 × 172.224 (H×V) |
| buitelyn (mm) | 122.2 × 210.95 × 3.95 (H×V×D) |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 850 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | - |
| kleurdiepte | 16.7M 63% NTSC |
| agterlig | 7S3P WLED , 15K hours , No Driver |
| massa | 130g (Max.) |
| gebruik vir | Pad & Tablet |
| herlaaitempo | 60Hz |
| raakskerm | PCAP, Optical Bonding |
| sein tipe | MIPI (4 data lanes) , 39 pins Connector |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: -20 ~ 60 °C |
