| Onderdeel nommer | TV080WUM-AK1 |
| Handelsmerk | BOE |
| Grootte | 8.0 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | a-Si TFT-LCD , Assem |
| Helderheid | |
| CR | 850:1 |
| Kleure | 16.7M |
| Agterlig | 7S3P |
| Koppelvlak | |
| paneel handelsmerk | BOE |
| paneel grootte | 8.0" |
| resolusie | 1200(RGB)×1920, WUXGA, 283PPI |
| vertoon area | 107.64(W)×172.224(H) mm |
| omtrek grootte | 122.2(W)×210.95(H) ×3.95(D) mm |
| helderheid | 350 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 63% NTSC |
| frekwensie | 60Hz |
| gewig | 130g (Max.) |
| paneel model | TV080WUM-AK1 |
| paneel tipe | a-Si TFT-LCD , Assembly |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | - |
| kontras verhouding | 850:1 (Typ.) (TM) |
| vertoonmodus | - |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| tipe lamp | 7S3P WLED , 15K hours , Without Driver |
| raakskerm | PCAP, Optical Bonding |
| aansoek | Pad & Tablet |
