| Onderdeel nommer | TV070WXM-TS0 |
| Handelsmerk | BOE |
| Grootte | 7.0 |
| Toepassing | Pad & Tablet |
| Resolusie | 800×1280 |
| Samestelling | Assembly , a-Si TF |
| Helderheid | |
| CR | 900:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| vervaardiger | BOE |
| skerm grootte | 7.0 inch |
| pixel nommer | 800(RGB)×1280 (WXGA) 215PPI |
| aktiewe area (mm) | 94.2 × 150.72 (H×V) |
| ring area (mm) | - |
| helderheid | 400 (Typ.)(cd/m²) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 16.7M 50% NTSC |
| massa | 74.5g (Typ.) |
| herlaaitempo | 60Hz |
| model naam | TV070WXM-TS0 |
| tipe skerm | Assembly , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 104.557 × 182.85 × 5.18 (H×V×D) |
| behandeling | Antiglare (Haze 25%), Hard coating |
| kontras verhouding | 900 : 1 (Typ.) (TM) |
| werksmodus | - |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| agterlig | WLED , 20K hours , No Driver |
| gebruik vir | Pad & Tablet |
| raakskerm | On-Cell Touch |
| A070VW08 V0 | AUO | 7.0 | 800×480 |
| AT070TN83 V.1 | Innolux | 7.0 | 800×480 |
| CLAA070NJ05CW | CPT | 7.0 | 1024×600 |
| HSD070I651-C02 | HannStar | 7.0 | 480×234 |
| HSD070PFW3-D00 | HannStar | 7.0 | 1024×600 |
| LD070WS2-SL01 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| LTA070B240F | TOSHIBA | 7.0 | 480×234 |
| N070ICE-G02 Rev.A2 | Innolux | 7.0 | 800×1280 |
| P070ACB-DB1 | Innolux | 7.0 | 600×1024 |
