| Onderdeel nommer | TV070HDM-TL0-39P0 |
| Handelsmerk | BOE |
| Grootte | 7.0 |
| Toepassing | Pad & Tablet |
| Resolusie | 720×1280 |
| Samestelling | a-Si TFT-LCD, Assemb |
| Helderheid | |
| CR | 900:1 |
| Kleure | 16.7M |
| Agterlig | 6S3P |
| Koppelvlak | MIPI |
| paneel handelsmerk | BOE |
| paneel model | TV070HDM-TL0-39P0 |
| paneel grootte | 7.0" |
| paneel tipe | a-Si TFT-LCD, Assembly |
| resolusie | 720(RGB)×1280, WXGA, 209PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 87.2654(W)×155.136(H) mm |
| ring opening | - |
| omtrek grootte | 93.08(W)×183.38(H) mm |
| oppervlak | Hard coating |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 900:1 (Typ.) (TM) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| vertoonmodus | - |
| beste uitsig op | Symmetry |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kleure vertoon | 16.7M 55% NTSC |
| tipe lamp | 6S3P WLED , Without Driver |
| frekwensie | 60Hz |
| raakskerm | On-Cell Touch |
| paneel gewig | 130g (Max.) |
| aansoek | Pad & Tablet |
| sein koppelvlak | MIPI (4 data lanes) , 39 pins Connector |
| insetspanning | 1.8/5.0/-5.0V (Typ.)(VDDI/VSP/VSN) |
| omgewing | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
| A070VW05 V2 | AUO | 7.0 | 800×480 |
| CLAA069LB02CW | CPT | 7.0 | 800×480 |
| CLAA070MA0ACW | CPT | 7.0 | 800×600 |
| CLAA070WA03 | CPT | 7.0 | 480×234 |
| LB070WV1-TD07 | LG Display | 7.0 | 800×480 |
| LB070WV1-TD08 | LG Display | 7.0 | 800×480 |
| LQ070T3AG02 | SHARP | 7.0 | 480×234 |
| LQ070Y3LG4A | SHARP | 7.0 | 800×480 |
| NL8048AC19-13 | NLT | 7.0 | 800×480 |
| TCG070WVLBA-A00 | Kyocera | 7.0 | 800×480 |
