| Onderdeel nommer | TPM0501010P |
| Handelsmerk | JDI |
| Grootte | 5.0 |
| Toepassing | Mobile Phone |
| Resolusie | 1080×1920 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | MIPI |
| handelsmerk | JDI |
| model | TPM0501010P |
| diagonale grootte | 5.0 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1080(RGB)×1920 [FHD] 445PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 61.641(H)×109.584(V) mm |
| buitelyn dof. | 64.04(H)×116.52(V) ×1.48(D) mm |
| helderheid | 450 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| bedryfsmodus | IPS, Normally Black, Transmissive |
| ondersteun kleur | 16.7M 85% NTSC |
| Ligbron | WLED [7S2P] , W/O Driver |
| gewig | TBD |
| ontwerp vir | Mobile Phone |
| raamkoers | 60Hz |
| raakpaneel | In-Cell Touch |
| koppelvlak tipe | MIPI (4 data lanes) , 40 pins Connector |
| kragtoevoer | 1.8/5.5/-5.5V (Typ.)(IOVCC/AVDD/AVEE) |
| omgewing | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| AT050TN43 V.1 | Innolux | 5.0 | 800×480 |
| ED050SC3 | E Ink | 5.0 | 800×600 |
| EE050NA-04A | Innolux | 5.0 | 640×480 |
| G050VTN01.1 | AUO | 5.0 | 800×480 |
| G050VVN01.0 | AUO | 5.0 | 480×800 |
| LMS501KF03 | Samsung | 5.0 | 480×800 |
| M050SWN1 R2 | IVO | 5.0 | 480×234 |
| PA050DT2 | E Ink | 5.0 | 320×234 |
| TM050LDZ00 | Tianma | 5.0 | 240×400 |
| TM050RDH03 | Tianma | 5.0 | 800×480 |
