| Onderdeel nommer | TM150TDSG80 |
| Handelsmerk | TIANMA |
| Grootte | 15.0 |
| Toepassing | Industrial |
| Resolusie | 1024×768 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | TIANMA |
| paneel model | TM150TDSG80 |
| paneel grootte | 15.0" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1024(RGB)×768, XGA, 85PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 304.128(W)×228.096(H) mm |
| ring opening | 307.4(W)×231.3(H) mm |
| omtrek grootte | 326.5(W)×253.5(H) ×10(D) mm |
| oppervlak | Antiglare |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| vertoonmodus | TN, Normally White, Transmissive |
| beste uitsig op | 12 o'clock |
| reaksie tyd | 8 (Typ.)(Tr+Td) |
| kleure vertoon | 262K/16.7M 60% NTSC |
| tipe lamp | WLED , 30K hours , With LED Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | TBD |
| aansoek | Industrial |
| sein koppelvlak | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -10 ~ 65 °C ; Storage Temp.: -20 ~ 65 °C |
