| Onderdeel nommer | TM133CFSP02 |
| Handelsmerk | TIANMA |
| Grootte | 13.3 |
| Toepassing | Laptop |
| Resolusie | 3840×2160 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 200:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | eDP |
| handelsmerk | TIANMA |
| model | TM133CFSP02 |
| diagonale grootte | 13.3 inch |
| tipe | a-Si TFT-LCD, CELL |
| pixel formaat | 3840(RGB)×2160 [UHD] 332PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 293.76(H)×165.24(V) mm |
| buitelyn dof. | 297.56(H)×173.74(V) ×1.24(D) mm |
| ring area | - |
| behandeling | Clear |
| helderheid | 0 cd/m² |
| kontras verhouding | 200:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 35 (Typ.)(Tr+Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedryfsmodus | SFT, Normally Black, Transmissive |
| plaat dikte | 0.50+0.50 mm |
| oordrag | - |
| ondersteun kleur | 16.7M |
| Ligbron | No B/L |
| vorm styl | - |
| ontwerp vir | Laptop |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | eDP (4 Lanes) , eDP1.4 , 40 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
