| Onderdeel nommer | TM123XDHP90 |
| Handelsmerk | TIANMA |
| Grootte | 12.3 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1920×720 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 10S4P |
| Koppelvlak | LVDS |
| paneel handelsmerk | TIANMA |
| paneel model | TM123XDHP90 |
| paneel grootte | 12.3" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1920(RGB)×720, 166PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 292.32(W)×109.62(H) mm |
| ring opening | - |
| omtrek grootte | 311(W)×130(H) ×15.7(D) mm |
| oppervlak | Antiglare (Haze 28%) |
| helderheid | 1000 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kykhoek | - |
| vertoonmodus | SFT, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kleure vertoon | 16.7M 98% sRGB |
| tipe lamp | 10S4P WLED , 10K hours , Without Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | 490g (Typ.) |
| aansoek | Industrial Outdoor High Brightness Automotive Display |
| sein koppelvlak | LVDS (2 ch, 8-bit) , 50 pins FPC |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
