| Onderdeel nommer | TM104TDGP10 |
| Handelsmerk | TIANMA |
| Grootte | 10.4 |
| Toepassing | Industrial |
| Resolusie | 1024×768 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1200:1 |
| Kleure | 262K/16.7M |
| Agterlig | 8S4P |
| Koppelvlak | LVDS |
| paneel handelsmerk | TIANMA |
| paneel grootte | 10.4" |
| resolusie | 1024(RGB)×768, XGA, 123PPI |
| vertoon area | 210.432(W)×157.824(H) mm |
| omtrek grootte | 230(W)×175.8(H) ×9.06(D) mm |
| helderheid | 450 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 262K/16.7M 50% NTSC |
| frekwensie | 60Hz |
| paneel gewig | 430g (Typ.) |
| sein koppelvlak | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| paneel model | TM104TDGP10 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 213.43(W)×160.82(H) mm |
| oppervlak | Antiglare |
| kontras verhouding | 1200:1 (Typ.) (TM) |
| vertoonmodus | SFT, Normally Black, Transmissive |
| reaksie tyd | 35 (Typ.)(Tr+Td) |
| tipe lamp | 8S4P WLED , With LED Driver |
| raakskerm | Without |
| aansoek | Industrial |
