| Onderdeel nommer | TM103XDHP95 |
| Handelsmerk | TIANMA |
| Grootte | 10.3 |
| Toepassing | Outdoor High Brightn |
| Resolusie | 1920×720 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 11S3P |
| Koppelvlak | |
| vervaardiger | TIANMA |
| model naam | TM103XDHP95 |
| skerm grootte | 10.3 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1920(RGB)×720 200PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 243.648 × 91.368 (H×V) |
| buitelyn (mm) | 261 × 110.5 × 14.65 (H×V×D) |
| ring area (mm) | 246.65 × 94.37 (H×V) |
| behandeling | Antiglare |
| helderheid | 950 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 88/88/88/88 (Typ.)(CR≥10) |
| reaksie | 35 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | SFT, Normally Black, Transmissive |
| kleurdiepte | 16.7M 99% sRGB |
| agterlig | 11S3P WLED , 10K hours , No Driver |
| massa | TBD |
| gebruik vir | Outdoor High Brightness Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| DJ103FA-01A | Innolux | 10.3 | 1920×720 |
